Procab PLS225/3
- Stock: Pre-Order
- Model: PLS225/3
Products Sold: 0
Product Views: 599
RM0.00
Ex Tax: RM0.00
PLS225
Loudspeaker cable - 2 x 2.5 mm² - 13 AWG - HighFlex™
Rental & MI
- Highflex™ solid & flexible jacket
- 2.5 mm² (13 AWG) thin and dense stranded conductors
- 8.5 mm (Ø) outer diameter
The PLS225 is a high quality loudspeaker cable consisting of two 2.5 mm² (13 AWG) conductors composed with 50 copper strands of 0.24 mm thickness. The combination of thin and dense strands with high purity copper and the flexible and solid PVC outer jacket makes it the perfect cable for various kinds of applications. The smooth outer jacket provides great ease of installation for fixed systems while having perfect rolling & unrolling performance for highly demanding mobile applications.
Specifications
Product features
| Application | Rental & MI |
| Series | Bulk & Accessories |
Physical characteristics
| Type of cable | 2-core loudspeaker cable | ||
| Inner conductor | Material | BC 50 x 0.24 mm (Ø) (OFC) | |
| Section | 2.5 mm² | ||
| Insulation | Material | PVC 3 mm (Ø) | |
| Number of conductors | 2 | ||
| American Wire Gauge | 13 AWG | ||
| Insulation | Colours | Red / Blue | |
| Conductor twisting | Yes | ||
| Outer jacket | Material | HighFlex™ NBR 8.5 mm (Ø) | |
| Colours | Black | ||
Mechanical characteristics
| Temperature range | Fixed installation | - 15 °C till + 70 °C |
| Mobile installation | - 5 °C till + 70 °C | |
| Bending radius | Fixed installation | 5 x outer diameter |
| Mobile installation | 10 x outer diameter |
Electrical characteristics
| Max. conductor | DC resistance | 7.98 (Ω / Km) |
| Resistance | Insulation | > 500 M Ω / km |
| Dielectric strength | 2 (KV / 1 min. DC) | |
| Rated voltage | 500 V | |
